CISCO Catalyst 9200L 48-port Data 4x10G uplink Switch Network Essentials

Продуктов код: 35974

Този продукт е неналичен.

Продуктът е временно изчерпан. Моля, оставете имейл или отправете своето запитване на support@hits.bg, за да Ви уведомим при нова наличност или предложим заместител.

Характеристика	Стойност
Арт. номера	C9200L-48T-4X-E

CISCO Catalyst 9200L 48-port Data 4x10G uplink Switch Network Essentials(müüdav ainult koos DNA litsentsidega)


Manufacturer	CISCO
Manufacturer Part No	C9200L-48T-4X-E

Marketing Description
The Cisco Catalyst 9200 Series switch can help customers simplify complexity, optimize IT, and reduce operational costs by leveraging intelligence, automation and human expertise. This switch provides security features that protect the integrity of the hardware as well as the software and all data that flows through the switch. It provides resiliency that keeps your business up and running seamlessly. The C9200L-48T-4X-E model has 48 ports 1G data with 4x 10G SFP+ fixed uplinks. Licensing is required.
General
Device Type	Switch - 48 ports - L3 - Managed - stackable
Enclosure Type	Rack-mountable
Subtype	Gigabit Ethernet
Ports	48 x 10/100/1000 + 4 x 10 Gigabit SFP+ (uplink)
Performance	Stacking bandwidth: 80 Gbps Switching capacity: 176 Gbps Forwarding rate: 261.9 Mpps
Capacity	Virtual networks: 1 IPv4 routes: 11000 IPv4 routing table entries: 3000 IPv6 routing table entries: 1500 Multicast scale: 1000 ACL scale entries: 1500 FNF entries: 16000 VLANs supported: 1024 Switched virtual interfaces (SVIs): 512 QoS hardware queues per port: 8
MAC Address Table Size	16000 entries
Jumbo Frame Support	9198 bytes
Routing Protocol	OSPF, RIP-1, RIP-2, EIGRP, VRRP, PIM-SM, EIGRP for IPv6, PIM-SSM, policy-based routing (PBR), RIPng, MSTP
Remote Management Protocol	SNMP 1, RMON 1, RMON 2, SNMP 3, SNMP 2c, CLI, NETCONF, RESTCONF
Features	QoS, Cisco StackWise Technology, Rapid PVST+, SRR, PXE support, RSPAN, NetFlow, Energy Efficient Ethernet, MIB, CoS, FNF, 802.1x authentication, DSCP support, MACsec support, 6MB packet buffer, CoPP, SPAN, EEM, PIM, FHS, PVLAN support, CIR
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3bz
RAM	2 GB
Flash Memory	4 GB
Expansion / Connectivity
Interfaces	48 x 1000Base-T RJ-45 4 x 10GBase-X SFP+ uplink 1 x network stack device 1 x management (LAN) RJ-45 1 x console RJ-45
Power
Power Device	Internal power supply - hot-plug
Max Supported Qty	2
Power Redundancy	Optional
Voltage Required	AC 100-240 V (50 - 60 Hz)
Miscellaneous
MTBF	508,700 hours
Compliant Standards	CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN 61000-6-1, AS/NZS 60950-1, CCC, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, RoHS, AS/NZS 3548 Class A, BSMI Class A, VCCI Class A, CNS 13438, EN 55022 Class A, FCC CFR47 Part 15 B Class A, EN 300 386, KN32, KN35, EN 55032 Class A, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, TCVN 7189 Class A, V-3 Class A, TCVN 7317, CISPR 35
Dimensions & Weight
Width	44.5 cm
Depth	4.4 cm
Height	28.8 cm
Weight	5 kg
Manufacturer Warranty
Service & Support	Limited warranty - advance parts replacement - lifetime - response time: next business day
Environmental Parameters
Humidity Range Operating	5 - 90% (non-condensing)
Min Storage Temperature	-40 °C
Max Storage Temperature	70 °C
Humidity Range Storage	5 - 90% (non-condensing)

Technical data provided by third party. We assume no liability for errors within these data.
