NETGEAR 10-Port Gb Smart Managed Pro Switch m. PoE
NETGEAR 10-Port Gb Smart Managed Pro Switch m. PoE
Лизингов калкулатор
| Характеристика | Стойност |
|---|---|
| Арт. номера |
GS110TP-300EUS
|
NETGEAR GS110TPv3 8 x 1G PoE+ Up to 55W 2 x SFP Smart Managed switch
| Manufacturer | NETGEAR | |
| Manufacturer Part No | GS110TP-300EUS | |
| Marketing Description | |
| The GS110TPv3 adds full 8 port PoE support for deployment of modern PoE devices. Cautious spender organizations can now deploy PoE devices connected to a cost effective switch, with a reasonable PoE power budget of 55W. Each port can provide up to 30 watts to power up connected devices. Fanless, the GS110TPv3 supports perfectly silent desktop operation or wall mounting. | |
| Product Features | |
|
|
| General | |
| Device Type | Switch - 8 ports - smart |
| Enclosure Type | Desktop, wall-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE) + 2 x SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 55 W |
| Performance | Switching fabric bandwidth: 20 Gbps Forwarding performance (64-byte packet size): 14.8 Mpps |
| Capacity | Packet buffer size: 512 KB ACL entries (ingress): 100 VLANs supported: 64 IPv4 routes (static): 32 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Routing Protocol | IGMPv2, IGMP, IGMPv3, static IPv4 routing, MLDv2, MLD |
| Remote Management Protocol | SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, IPv6 |
| Encryption Algorithm | TLS 1.2 |
| Authentication Method | RADIUS, TACACS+ |
| Features | IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, store and forward, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, firmware upgradable, STP support, RSTP support, MSTP support, DHCP snooping, ACL support, MLD snooping, fanless, LACP, DHCP client, dual firmware images, loop prevention, tagged VLAN, cable test, LLDP-MED, protected ports, EEE, WRR, Advanced QoS, Unknown Storm Control, security slot (Kensington security lock compatible) |
| Compliant Standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az |
| Processor | : 500 MHz |
| RAM | 128 MB |
| Flash Memory | 32 MB |
| Status Indicators | Port status, PoE, link/activity/speed |
| Expansion / Connectivity | |
| Interfaces | 8 x 1000Base-T RJ-45 PoE+ 2 x 1000Base-X SFP |
| Power | |
| Power Device | External power adapter |
| Voltage Required | DC 54 V |
| Power Consumption Operational | 69.5 Watt |
| Power Consumption Stand by | 4.3 Watt |
| Miscellaneous | |
| Included Accessories | Wall mounting kit |
| MTBF | 1,200,041 hours |
| Localisation | Europe |
| Dimensions & Weight | |
| Width | 23.6 cm |
| Depth | 10.1 cm |
| Height | 2.7 cm |
| Weight | 610 g |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - replacement - lifetime - response time: next business day Limited warranty - power supply - 2 years Technical support - phone consulting - 90 days |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 40 °C |
| Humidity Range Operating | 95% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 95% (non-condensing) |
Technical data provided by third party. We assume no liability for errors within these data.
